302-4-Flute-HP-Solid Carbide Ball Nose upto 60HRc machining -Metric

Description
  • High Performance¬†Carbide Ball Nose for Die-Mold Application for running at higher parameters.
  • Performs better than 206 series (TX series) of Carbide Ball Nose End Mills.
  • 4-Flute Carbide Ball Nose End Mills comes with newly developed NOVA coating.
  • Solid Carbide Ball Nose for milling up to 60-HRc hardened die steel & tool steel like D2, D3, H13 etc.

Item Variants

Item Code Flute Dia (mm) Flute Length (mm) Shank Dia (mm) Overall Length (mm)
CR33HBE00364 3 15 3 50

CR33HBE00372 6 25 6 75

CR33HBE009S4 2 4 3 50

CR33HBE009T2 2.5 4 3 38

CR33HBE009U0 2.5 5 3 50

CR33HBE009V8 3 5 3 38

CR33HBE009W6 3 6 3 50

CR33HBE009X3 3 6 3 75

CR33HBE009Y1 3 6 3 100

CR33HBE00A03 4 8 4 50

CR33HBE00A11 4 8 4 75

CR33HBE00A29 4 8 4 100

CR33HBE00A37 5 10 5 50

CR33HBE00A45 5 10 5 75

CR33HBE00A52 5 10 5 100

CR33HBE00A60 6 12 6 50

CR33HBE00A78 6 12 6 75

CR33HBE00A86 6 12 6 100

CR33HBE00A94 6 12 6 150

CR33HBE00AA6 8 16 8 60

CR33HBE00AB4 8 16 8 75

CR33HBE00AC2 8 16 8 100

CR33HBE00AD9 8 16 8 150

CR33HBE00AE7 10 20 10 75

CR33HBE00AF5 10 20 10 100

CR33HBE00AG3 10 20 10 150

CR33HBE00AH1 12 25 12 75

CR33HBE00AJ6 12 25 12 100

CR33HBE00AK4 12 25 12 150

CR33HBE00BB3 6 30 6 100

CR33HBE00BV9 4 14 4 50

CR33HBE00BW7 6 16 6 50

CR33HBE00BY2 10 25 10 75

CR33HBE00C50 5 16 5 50

CR33HBE00C92 8 20 8 60
