401-4-Flute-HP-Solid Carbide Flat End Mills upto 65HRc machining-Metric

Description
  • High Performance Carbide End Mills for Die-Mold Industry developed at RIGPL.
  • ~ 2-Times Cutting Tool life is achieved in comparison to 301 Series Carbide End mills.
  • ~ 2-Times Cutting Parameters are achieved in comparison to 301 Series Carbide End mills.
  • 4-Flute Carbide End Mills manufactured from NG (Nano-Grain) carbide
  • Solid Carbide Cutting Tools for milling up to 65-HRc hardened die steel & tool steel like D2, D3, H13 etc.

Item List

Item Flute Dia (mm) Flute Length (mm) Shank Dia (mm) Overall Length (mm)
CR49HSE00JU8 3 12 4 50

CR49HSE00JV6 4 12 4 50

CR49HSE00JW4 4 20 4 75

CR49HSE00JX1 6 16 6 50

CR49HSE00JY9 6 25 6 75

CR49HSE00JZ7 8 25 8 75

CR49HSE00K08 8 30 8 100

CR49HSE00K16 10 25 10 75

CR49HSE00K24 10 40 10 100

CR49HSE00K32 12 25 12 75

CR49HSE00K40 12 40 12 100

CR4AHSE00ML7 8 20 8 60

CR4AHSE00T43 1 2 4 50

CR4AHSE00T50 2 4 4 50

CR4AHSE00T68 1.5 3 4 50
