CTHS-Steel-Coolant Fed Solid Carbide Drills-Short-Metric

Description
  • These Coolant Fed Carbide Drill Bits have new chip curling design to enable chip breakage
  • At least 15-Bar of Coolant Pressure is recommended for best of use of these Carbide Drills
  • These Coolant Fed Carbide Drill Bits are best suited for drilling MS, Alloy Steel, Cast Iron up to 450BHN, Stainless Steel
  • These Coolant Fed Carbide Drill bits comes with Edge Chamfer & edge preparation for longer drill life
  • These Carbide Cutting Tools Comes with newly developed PEROX coating for higher Vc and Feed rates to improve your productivity
(Note only for indication the image of NOVA Coated drill is shown, however you will get PEROX Coated Carbide Drills for better performance)

Item List

Item Flute Dia (mm) Flute Length (mm) Shank Dia (mm) Overall Length (mm)
CR3PHDR00PD5 3 20 4 62

CR3PHDR00PE3 3.1 20 4 62

CR3PHDR00PF1 3.2 20 4 62

CR3PHDR00PG9 3.3 20 4 62

CR3PHDR00PH7 3.4 20 4 62

CR3PHDR00PJ2 3.5 20 4 62

CR3PHDR00PK0 3.6 20 4 62

CR3PHDR00PL8 3.7 20 4 62

CR3PHDR00PM6 3.8 24 4 62

CR3PHDR00PN3 3.9 24 4 62

CR3PHDR00PP9 4 24 4 62

CR3PHDR00PQ7 4.1 24 6 62

CR3PHDR00PR5 4.2 24 6 62

CR3PHDR00PS2 4.3 24 6 62

CR3PHDR00PT0 4.4 24 6 62

CR3PHDR00PU8 4.5 24 6 62

CR3PHDR00PV6 4.6 24 6 62

CR3PHDR00PW4 4.7 24 6 62

CR3PHDR00PX1 4.8 28 6 62

CR3PHDR00PY9 4.9 28 6 62

CR3PHDR00PZ7 5 28 6 62

CR3PHDR00Q08 5.1 28 6 62

CR3PHDR00Q16 5.2 28 6 62

CR3PHDR00Q24 5.3 28 6 62

CR3PHDR00Q32 5.4 28 6 62

CR3PHDR00Q40 5.5 28 6 62

CR3PHDR00Q57 5.6 28 6 62

CR3PHDR00Q65 5.7 28 6 62

CR3PHDR00Q73 5.8 28 6 62

CR3PHDR00Q81 5.9 28 6 62

CR3PHDR00Q99 6 28 6 62

CR3PHDR00QA1 6.1 34 8 75

CR3PHDR00QB9 6.2 34 8 75

CR3PHDR00QC7 6.3 34 8 75

CR3PHDR00QD4 6.4 34 8 75

CR3PHDR00QE2 6.5 34 8 75

CR3PHDR00QF0 6.6 34 8 75

CR3PHDR00QG8 6.7 34 8 75

CR3PHDR00QH6 6.8 34 8 75

CR3PHDR00QJ1 6.9 34 8 75

CR3PHDR00QK9 7 34 8 75

CR3PHDR00QL7 7.1 40 8 80

CR3PHDR00QM5 7.2 40 8 80

CR3PHDR00QN2 7.3 40 8 80

CR3PHDR00QP8 7.4 40 8 80

CR3PHDR00QQ6 7.5 40 8 80

CR3PHDR00QR4 7.6 40 8 80

CR3PHDR00QS1 7.7 40 8 80

CR3PHDR00QT9 7.8 40 8 80

CR3PHDR00QU7 7.9 40 8 80

CR3PHDR00QV5 8 40 8 80

CR3PHDR00QW3 8.1 40 10 80

CR3PHDR00QX0 8.2 40 10 80

CR3PHDR00QY8 8.3 40 10 80

CR3PHDR00QZ6 8.4 40 10 80

CR3PHDR00R07 8.5 40 10 80

CR3PHDR00R15 8.6 40 10 80

CR3PHDR00R23 8.7 40 10 80

CR3PHDR00R31 8.8 40 10 80

CR3PHDR00R49 8.9 40 10 80

CR3PHDR00R56 9 40 10 80

CR3PHDR00R64 9.1 40 10 80

CR3PHDR00R72 9.2 40 10 80

CR3PHDR00R80 9.3 40 10 80

CR3PHDR00R98 9.4 40 10 80

CR3PHDR00RA0 9.5 40 10 80

CR3PHDR00RB8 9.6 40 10 80

CR3PHDR00RC6 9.7 40 10 80

CR3PHDR00RD3 9.8 40 10 80

CR3PHDR00RE1 9.9 40 10 80

CR3PHDR00RF9 10 40 10 80

CR3PHDR00RG7 8.1 51 10 100

CR3PHDR00RH5 8.2 51 10 100

CR3PHDR00RJ0 8.3 51 10 100

CR3PHDR00RK8 8.4 51 10 100

CR3PHDR00RL6 8.5 51 10 100

CR3PHDR00RM4 8.6 51 10 100

CR3PHDR00RN1 8.7 51 10 100

CR3PHDR00RP7 8.8 51 10 100

CR3PHDR00RQ5 8.9 51 10 100

CR3PHDR00RR3 9 51 10 100

CR3PHDR00RS0 9.1 51 10 100

CR3PHDR00RT8 9.2 51 10 100

CR3PHDR00RU6 9.3 51 10 100

CR3PHDR00RV4 9.4 51 10 100

CR3PHDR00RW2 9.5 51 10 100

CR3PHDR00RX9 9.6 51 10 100

CR3PHDR00RY7 9.7 51 10 100

CR3PHDR00RZ5 9.8 51 10 100

CR3PHDR00S06 9.9 51 10 100

CR3PHDR00S14 10 51 10 100

CR3PHDR00S22 10.1 55 12 100

CR3PHDR00S30 10.2 55 12 100

CR3PHDR00S48 10.3 55 12 100

CR3PHDR00S55 10.4 55 12 100

CR3PHDR00S63 10.5 55 12 100

CR3PHDR00S71 10.6 55 12 100

CR3PHDR00S89 10.7 55 12 100

CR3PHDR00S97 10.8 55 12 100

CR3PHDR00SA9 10.9 55 12 100

CR3PHDR00SB7 11 55 12 100

CR3PHDR00SC5 11.1 55 12 100

CR3PHDR00SD2 11.2 55 12 100

CR3PHDR00SE0 11.3 55 12 100

CR3PHDR00SF8 11.4 55 12 100

CR3PHDR00SG6 11.5 55 12 100

CR3PHDR00SH4 11.6 55 12 100

CR3PHDR00SJ9 11.7 55 12 100

CR3PHDR00SK7 11.8 55 12 100

CR3PHDR00SL5 11.9 55 12 100

CR3PHDR00SM3 12 55 12 100

CR3PHDR00SN0 12.5 55 14 105

CR3PHDR00SP6 13 55 14 105

CR3PHDR00SQ4 13.5 55 14 105

CR3PHDR00SR2 14 55 14 105

CR3PHDR00SS9 14.5 58 16 105

CR3PHDR00ST7 15 58 16 105

CR3PHDR00SU5 15.5 58 16 105

CR3PHDR00SV3 16 58 16 105

CR3PHDR00SW1 16.5 58 18 105

CR3PHDR00SX8 17 58 18 105

CR3PHDR00SY6 17.5 58 18 105

CR3PHDR00SZ4 18 58 18 105

CR3PHDR00T05 18.5 58 20 105

CR3PHDR00T13 19 58 20 105

CR3PHDR00T21 19.5 58 20 105

CR3PHDR00T39 20 58 20 105
