C1GS-GP-Stub Solid Carbide Drills-Metric

Description

Carbide Stub Drills Bits are used for General Drilling for wide range of materials,
These Carbide Drill Bits have Better Life & productivity in comparison to HSS Co drills,
These Carbide Cutting Tools are useful for below 5 L/D drilling applications
Stub Carbide Drill Bits are manufactured with TiALN or FUTURA or TIN coating
These Cutting Tools are Good for small batch production.

Item List

Item	Flute Dia (mm)	Flute Length (mm)	Shank Dia (mm)	Overall Length (mm)
CR11GDR004U3	2	12	2	39
CR11GDR004Y4	2.1	14	2.1	39
CR11GDR004Z2	2.2	14	2.2	39
CR11GDR00503	2.3	14	2.3	39
CR11GDR00511	2.4	14	2.4	39
CR11GDR00529	2.5	14	2.5	39
CR11GDR00545	2.6	20	2.6	54
CR11GDR00552	2.7	20	2.7	54
CR11GDR00560	2.8	20	2.8	54
CR11GDR00586	2.9	20	2.9	54
CR11GDR00594	3	20	3	54
CR11GDR005C2	3.1	20	3.1	54
CR11GDR005E7	3.2	20	3.2	54
CR11GDR005G3	3.3	20	3.3	54
CR11GDR005J6	3.4	20	3.4	54
CR11GDR005M0	3.5	20	3.5	54
CR11GDR005P3	3.6	22	3.6	54
CR11GDR005R9	3.7	22	3.7	54
CR11GDR005T4	3.8	22	3.8	54
CR11GDR005V0	3.9	22	3.9	54
CR11GDR005X5	4	22	4	54
CR11GDR005Z1	4.1	24	4.1	63
CR11GDR00610	4.2	24	4.2	63
CR11GDR00636	4.3	24	4.3	63
CR11GDR00651	4.4	24	4.4	63
CR11GDR00677	4.5	24	4.5	63
CR11GDR006A5	4.6	26	4.6	63
CR11GDR006C1	4.7	26	4.7	63
CR11GDR006E6	4.8	26	4.8	63
CR11GDR006G2	4.9	26	4.9	63
CR11GDR006J5	5	26	5	63
CR11GDR006L1	5.1	28	5.1	63
CR11GDR006N6	5.2	28	5.2	63
CR11GDR006R8	5.3	28	5.3	63
CR11GDR006U1	5.4	28	5.4	63
CR11GDR006W7	5.5	28	5.5	63
CR11GDR006Y2	5.6	28	5.6	63
CR11GDR00701	5.7	28	5.7	63
CR11GDR00727	5.8	28	5.8	63
CR11GDR00743	5.9	28	5.9	63
CR11GDR00768	6	28	6	63
CR11GDR00784	6.1	31	6.1	63
CR11GDR007A4	6.2	31	6.2	63
CR11GDR007D7	6.3	31	6.3	63
CR11GDR007F3	6.4	31	6.4	63
CR11GDR007J4	6.5	31	6.5	63
CR11GDR007L0	6.6	34	6.6	63
CR11GDR007N5	6.7	34	6.7	63
CR11GDR007Q9	6.8	34	6.8	63
CR11GDR007T2	6.9	34	6.9	63
CR11GDR007W6	7	34	7	63
CR11GDR007Y1	7.1	34	7.1	79
CR11GDR00800	7.2	34	7.2	79
CR11GDR00826	7.3	34	7.3	79
CR11GDR00842	7.4	34	7.4	79
CR11GDR00867	7.5	34	7.5	79
CR11GDR008A3	7.6	37	7.6	79
CR11GDR008C9	7.7	37	7.7	79
CR11GDR008E4	7.8	37	7.8	79
CR11GDR008G0	7.9	37	7.9	79
CR11GDR008J3	8	37	8	79
CR11GDR008L9	8.1	37	8.1	79
CR11GDR008N4	8.2	37	8.2	79
CR11GDR008R6	8.3	37	8.3	79
CR11GDR008T1	8.4	37	8.4	79
CR11GDR008W5	8.5	37	8.5	79
CR11GDR00909	8.6	40	8.6	79
CR11GDR00933	8.7	40	8.7	79
CR11GDR00958	8.8	40	8.8	79
CR11GDR00982	8.9	40	8.9	79
CR11GDR009A2	9	40	9	79
CR11GDR009E3	9.1	40	9.1	79
CR11GDR009G9	9.2	40	9.2	79
CR11GDR009J2	9.3	40	9.3	79
CR11GDR009L8	9.4	40	9.4	79
CR11GDR009N3	9.5	40	9.5	79
CR11GDR009Q7	9.6	42	9.6	79
CR11GDR009S2	9.7	42	9.7	79
CR11GDR009V6	9.8	42	9.8	79
CR11GDR009X1	9.9	42	9.9	79
CR11GDR009Z7	10	42	10	79
CR11GDR00A19	10.1	42	10.1	79
CR11GDR00A27	10.2	42	10.2	79
CR11GDR00A43	10.3	47	10.3	100
CR11GDR00A50	10.4	47	10.4	100
CR11GDR00A68	10.5	47	10.5	100
CR11GDR00A92	10.6	47	10.6	100
CR11GDR00AA4	10.7	47	10.7	100
CR11GDR00AB2	10.8	47	10.8	100
CR11GDR00AD7	10.9	47	10.9	100
CR11GDR00AE5	11	47	11	100
CR11GDR00AG1	11.1	47	11.1	100
CR11GDR00AH9	11.2	47	11.2	100
CR11GDR00AJ4	11.3	47	11.3	100
CR11GDR00AK2	11.4	47	11.4	100
CR11GDR00AL0	11.5	47	11.5	100
CR11GDR00AN5	11.6	49	11.6	100
CR11GDR00AP1	11.7	49	11.7	100
CR11GDR00AQ9	11.8	49	11.8	100
CR11GDR00AR7	11.9	49	11.9	100
CR11GDR00AS4	12	49	12	100
CR11GDR00AU0	12.1	51	12.1	102
CR11GDR00AV8	12.2	51	12.2	102
CR11GDR00AW6	12.3	51	12.3	102
CR11GDR00AX3	12.4	51	12.4	102
CR11GDR00AZ9	12.5	51	12.5	102
CR11GDR00B00	12.6	51	12.6	102
CR11GDR00B18	12.7	51	12.7	102
CR11GDR00B34	12.8	51	12.8	102
CR11GDR00B42	12.9	51	12.9	102
CR11GDR00B59	13	51	13	102
CR11GDR00B67	13.1	54	13.1	107
CR11GDR00B75	13.2	54	13.2	107
CR11GDR00B83	13.3	54	13.3	107
CR11GDR00B91	13.4	54	13.4	107
CR11GDR00BA3	13.5	54	13.5	107
CR11GDR00BB1	13.6	54	13.6	107
CR11GDR00BC9	13.7	54	13.7	107
CR11GDR00BD6	13.8	54	13.8	107
CR11GDR00BE4	13.9	54	13.9	107
CR11GDR00BF2	14	54	14	107
CR11GDR00BG0	14.1	56	14.1	109
CR11GDR00BH8	14.2	56	14.2	109
CR11GDR00BJ3	14.3	56	14.3	109
CR11GDR00BK1	14.4	56	14.4	109
CR11GDR00BL9	14.5	56	14.5	109
CR11GDR00BM7	14.6	56	14.6	109
CR11GDR00BN4	14.7	56	14.7	109
CR11GDR00BP0	14.8	56	14.8	109
CR11GDR00BQ8	14.9	56	14.9	109
CR11GDR00BS3	15	56	15	109
CR11GDR00BT1	16	56	16	109
CR11GDR00BU9	17	56	17	109
CR11GDR00BV7	18	56	18	109
CR11GDR00BW5	19	56	19	109
CR11GDR00BX2	20	56	20	109
