C3HS-Steel-High Performance Solid Carbide Drills-Short-Metric

Description

These Carbide Drill Bits have new chip curling design to enable chip breakage
3~4 Times production compared to General Carbide Drill Bits like C1GS, C1GJ series
These Carbide Drill Bits are best suited for drilling MS, Alloy Steel, Cast Iron upto 450BHN, Stainless Steel
Carbide Drill bits comes with Edge Chamfer and better edge preparation for longer drill life
These Carbide Cutting Tools Comes with newly developed NOVA coating.

Item List

Item	Flute Dia (mm)	Flute Length (mm)	Shank Dia (mm)	Overall Length (mm)
CR3AHDR00C23	2	14	4	50
CR3AHDR00C31	2.1	14	4	50
CR3AHDR00C49	2.2	14	4	50
CR3AHDR00C56	2.3	14	4	50
CR3AHDR00C64	2.4	14	4	50
CR3AHDR00C72	2.5	14	4	50
CR3AHDR00C80	2.6	14	4	50
CR3AHDR00C98	2.7	14	4	50
CR3AHDR00CA0	2.8	14	4	50
CR3AHDR00CB8	2.9	14	4	50
CR3AHDR00CC6	3	20	6	62
CR3AHDR00CD3	3.1	20	6	62
CR3AHDR00CE1	3.2	20	6	62
CR3AHDR00CF9	3.3	20	6	62
CR3AHDR00CG7	3.4	20	6	62
CR3AHDR00CH5	3.5	20	6	62
CR3AHDR00CJ0	3.6	20	6	62
CR3AHDR00CK8	3.7	20	6	62
CR3AHDR00CL6	3.8	24	6	62
CR3AHDR00CM4	3.9	24	6	62
CR3AHDR00CN1	4	24	6	62
CR3AHDR00CP7	4.1	24	6	62
CR3AHDR00CQ5	4.2	24	6	62
CR3AHDR00CR3	4.3	24	6	62
CR3AHDR00CS0	4.4	24	6	62
CR3AHDR00CT8	4.5	24	6	62
CR3AHDR00CU6	4.6	24	6	62
CR3AHDR00CV4	4.7	24	6	62
CR3AHDR00CW2	4.8	28	6	62
CR3AHDR00CX9	4.9	28	6	62
CR3AHDR00CY7	5	28	6	62
CR3AHDR00CZ5	5.1	28	6	62
CR3AHDR00D06	5.2	28	6	62
CR3AHDR00D14	5.3	28	6	62
CR3AHDR00D22	5.4	28	6	62
CR3AHDR00D30	5.5	28	6	62
CR3AHDR00D48	5.6	28	6	62
CR3AHDR00D55	5.7	28	6	62
CR3AHDR00D63	5.8	28	6	62
CR3AHDR00D71	5.9	28	6	62
CR3AHDR00D89	6	28	6	62
CR3AHDR00D97	6.1	34	8	75
CR3AHDR00DA9	6.2	34	8	75
CR3AHDR00DB7	6.3	34	8	75
CR3AHDR00DC5	6.4	34	8	75
CR3AHDR00DD2	6.5	34	8	75
CR3AHDR00DE0	6.6	34	8	75
CR3AHDR00DF8	6.7	34	8	75
CR3AHDR00DG6	6.8	34	8	75
CR3AHDR00DH4	6.9	34	8	75
CR3AHDR00DJ9	7	34	8	75
CR3AHDR00DK7	7.1	40	8	80
CR3AHDR00DL5	7.2	40	8	80
CR3AHDR00DM3	7.3	40	8	80
CR3AHDR00DN0	7.4	40	8	80
CR3AHDR00DP6	7.5	40	8	80
CR3AHDR00DQ4	7.6	40	8	80
CR3AHDR00DR2	7.7	40	8	80
CR3AHDR00DS9	7.8	40	8	80
CR3AHDR00DT7	7.9	40	8	80
CR3AHDR00DU5	8	40	8	80
CR3AHDR00DV3	8.1	51	10	100
CR3AHDR00DW1	8.2	51	10	100
CR3AHDR00DX8	8.3	51	10	100
CR3AHDR00DY6	8.4	51	10	100
CR3AHDR00DZ4	8.5	51	10	100
CR3AHDR00E05	8.6	51	10	100
CR3AHDR00E13	8.7	51	10	100
CR3AHDR00E21	8.8	51	10	100
CR3AHDR00E39	8.9	51	10	100
CR3AHDR00E47	9	51	10	100
CR3AHDR00E54	9.1	51	10	100
CR3AHDR00E62	9.2	51	10	100
CR3AHDR00E70	9.3	51	10	100
CR3AHDR00E88	9.4	51	10	100
CR3AHDR00E96	9.5	51	10	100
CR3AHDR00EA8	9.6	51	10	100
CR3AHDR00EB6	9.7	51	10	100
CR3AHDR00EC4	9.8	51	10	100
CR3AHDR00ED1	9.9	51	10	100
CR3AHDR00EE9	10	51	10	100
CR3AHDR00EF7	10.1	55	12	100
CR3AHDR00EG5	10.2	55	12	100
CR3AHDR00EH3	10.3	55	12	100
CR3AHDR00EJ8	10.4	55	12	100
CR3AHDR00EK6	10.5	55	12	100
CR3AHDR00EL4	10.6	55	12	100
CR3AHDR00EM2	10.7	55	12	100
CR3AHDR00EN9	10.8	55	12	100
CR3AHDR00EP5	10.9	55	12	100
CR3AHDR00EQ3	11	55	12	100
CR3AHDR00ER1	11.1	55	12	100
CR3AHDR00ES8	11.2	55	12	100
CR3AHDR00ET6	11.3	55	12	100
CR3AHDR00EU4	11.4	55	12	100
CR3AHDR00EV2	11.5	55	12	100
CR3AHDR00EW0	11.6	55	12	100
CR3AHDR00EX7	11.7	55	12	100
CR3AHDR00EY5	11.8	55	12	100
CR3AHDR00EZ3	11.9	55	12	100
CR3AHDR00F04	12	55	12	100
CR3AHDR00F12	12.5	55	14	105
CR3AHDR00F20	13	55	14	105
CR3AHDR00F38	13.5	55	14	105
CR3AHDR00F46	14	55	14	105
CR3AHDR00F53	14.5	58	16	105
CR3AHDR00F61	15	58	16	105
CR3AHDR00F79	15.5	58	16	105
CR3AHDR00F87	16	58	16	105
CR3AHDR00F95	16.5	58	18	105
CR3AHDR00FA7	17	58	18	105
CR3AHDR00FB5	17.5	58	18	105
CR3AHDR00FC3	18	58	18	105
CR3AHDR00FD0	18.5	58	20	105
CR3AHDR00FE8	19	58	20	105
CR3AHDR00FF6	19.5	58	20	105
CR3AHDR00FG4	20	58	20	105
CR3AHDR00NH4	8.4	40	10	75
CR3AHDR00NJ9	8.5	40	10	75
CR3AHDR00NK7	8.6	40	10	75
CR3AHDR00NL5	10.4	40	12	75
CR3AHDR00NM3	10.5	40	12	75
CR3AHDR00NN0	10.3	40	12	75
CR3AHDR00NP6	8.3	40	10	75
CR3AHDR00NR2	8.7	40	10	75
CR3AHDR00NS9	10.6	40	12	75
CR3AHDR00NT7	15.8	58	16	100
CR3AHDR00NV3	8.2	40	10	80
CR3AHDR00NW1	9	40	10	80
CR3AHDR00NX8	10	40	10	80
CR3AHDR00NY6	14.6	40	16	80
CR3AHDR00NZ4	8.8	40	10	80
CR3AHDR00P20	12.7	55	14	105
CR3AHDR00P38	13.1	55	14	105
CR3AHDR00P46	13.2	55	14	105
CR3AHDR00P53	8.1	40	10	80
CR3AHDR00P79	9.1	40	10	80
CR3AHDR00P87	9.3	40	10	80
CR3AHDR00P95	9.5	40	10	80
CR3AHDR00PA7	9.8	40	10	80
CR3AHDR00PB5	12.2	55	14	105
CR3AHDR00TQ8	9.2	40	10	80
CR3AHDR00TS3	13.8	55	14	105
CR3AHDR00TU9	8.9	40	10	80
CR3AHDR00TV7	9.4	40	10	80
CR3AHDR00TW5	9.6	40	10	80
CR3AHDR00TX2	9.7	40	10	80
CR3AHDR00TY0	9.9	40	10	80
CR3AHDR00U33	12.8	55	14	105
CR3AHDR00U41	14.2	58	16	105
CR3AHDR00U58	12.3	55	14	105
CR3AHDR00U66	1.5	8	3	50
CR3AHDR00U74	1.6	8	3	50
CR3AHDR00U82	1.7	8	3	50
CR3AHDR00U90	1.8	10	3	50
CR3AHDR00UA2	1.9	11	3	50
CR3AHDR00VD4	13.3	55	14	105
